MOUNTED COMBINATION DRILLS

JET-M

Rear mounted combination drill

The Jet M pneumatic seed drill is designed for ease-of-use and maximum versatility. It is compatible with Alpego BG, RMT or RTEK power harrows and suitable for working in combination with tractors from 85 to 250hp.

355mm Boron steel single disc coulters
- Anti-block flap
- Twin bearings
- 60kg coulter pressure
- Rubber shock protecting mounts
- protecting coulter arm mounts
- 43cm coulter stagger

Quick attach
“Fast” - Flexible configuration that allows the seeder to be detached from the implement very quickly (in less than 10 minutes) in order to use the harrow independently (For BG power harrows)

“Auto level” - Maximum precision configuration thanks to the attachment of the seeding bar to the rear roller that allows the seeding depth to be maintained even when changing the working depth of the power harrow. The complete seeding bar or complete drill can be demounted  in around 15 minutes to allow independent use of the power harrow (For RMT and RTEK power harrows)

RDS Super-Plus control box & GPS speed sensor
- Manages seeding operation and tramlines
- Pre start metering function
- Monitors fan, metering roller and seed level

Stainless steel AIRON electronic metering unit
- 3 interchangeable metering rollers
- Seed rates from 2-350kg/ha

1000 litre hopper
Hydraulic drive fan
Manual half width shut off
2+2 tramlines

JET-X

Rear mounted combination drill

The Jet X pneumatic seed drill is designed for professional use and suitable for drilling all seed types in the most demanding conditions. It is compatible with Alpego RTEK and RMAX power harrows and suitable for working in combination with tractors from 120 to 320hp.

355mm Boron steel single disc coulters
- Anti-block flap
- Twin bearings
- 60kg coulter pressure
- Rubber shock protecting mounts
- protecting coulter arm mounts
- 43cm coulter stagger

Quick attach
“Auto level” - Maximum precision configuration thanks to the attachment of the seeding bar to the rear roller that allows the seeding depth to be maintained even when changing the working depth of the power harrow. The complete seeding bar or complete drill can be demounted in around 15 minutes to allow independent use of the power harrow (For RTEK and RMAX power harrows)

Full ISOBUS drill management using the tractor screen

Stainless steel DOSAL electronic metering unit
- Capable of 2 to 450kg/ha
- Single variable displacement roller for large and small seeds

Turbo rotal impeller in distribution head
- Precise, even seed distribution

Extendable 1500 litre hopper
Hydraulic drive fan
Electric half width shut off
2+2 tramlines

SEED BED PREPARATION AND SEEDING

A coulter bar for all conditions

Parallelogram mounted roller
Alpego use a parallelogram linkage between the power harrow and rear roller. This ensures the angle of the frame that the drill is mounted on stays the same also allowing the power harrow depth to be adjusted without affecting the coulter pressure or depth.

Seeding bar adjustment
There is also a parallelogram linkage to adjust the coulter depth, this ensures the coulter bar stays parallel to the ground and therefore the front and rear coulter depth pressure is the same.

Coulter spacing
There is 43cm clearance between the two rows of coulters which ensures crop residues and soil flows through the discs even in sticky wet conditions.

Press wheel
An optional rubber press wheel is available to help maintain consistent depth when drilling shallow and improved seed to soil contact.

A - Rubber shock absorber: Discs are mounted on a rubber shock absorbing clamp that allows up to 60kg of coulter pressure.

B - Single boron disc: 355mm Boron steel discs provide consistent penetration and longevity.

C - Double roller bearing: Alpego disc coulters are mounted on two roller bearings for reliable work in tough conditions.

D - seed flap: A seed flap behind the coulter tube prevents blockage in wet conditions.

AIRON

Precise gentle metering for small and large seeds

Stainless steel metering unit suitable for large and small seeds and Fertiliser.

The AIRON metering unit has been designed to provide simplicity and ease of use from the calibration test, through to cleaning out when drilling is finished. It utilises interchangeable metering rollers as well as adjustable gears to allow metering of various of seed types and fertiliser and features simple manual half side shut off.

DOSAL

Accurate high capacity metering.

Stainless steel metering unit suitable for large and small seeds and Fertiliser.

The Flexible DOSAL metering unit is designed for maximum volumes alongside precision for small seeds. It utilises an adjustable metering roller and adjustable gears to achieve unbeatable accuracy with small and large seeds as well as fertiliser.

TURBO ROTAL

(JET-X ONLY)

Even distribution for uniform application

The Turbo Rotal system is an innovative solution for an issue that affects all drills especially when using long seed pipes at wider working widths. It consists of a spinning impeller located in the centre of the distribution head that promotes more uniform distribution of the seed to the individual outlets.

This improves the consistency of seed volume delivered to each outlet by 50% which, coupled with Alpego attention to detail throughout the other elements of the metering and distribution, provides market leading accuracy.

Super-Plus (Jet-M)

• Manages seeding operation
• Push button calibration
• Pre start metering function
• Monitors fan, metering roller and seed level
• On the move seed rate adjustment
• GPS speed sensor

ISOBUS (Jet-X)

Isobus control through the tractor screen

• Full management of the drilling and tramlines
• Push button calibration
• Pre start metering function
• Fan, metering roller and low level monitoring
• On the move seed rate adjustment

TC7 (Jet-X)

• 7” high resolution colour touch-screen (800x480TFT)
• 2 USB ports for data transfer
• RS232 serial port
• Camera input
• CAN-BUS connector
• Wireless interface from rear USB
• Additional liscenced functions available,
• Task Control (TC), Section control (TCSC), Variable rate (VRC).

Option for tractors without ISOBUS
